Model Name PRO B760M-P DDR4

CPU Support Support Intel®

Core™ 14th/ 13th/ 12th Gen Processors, Intel®

Pentium®

Gold and Celeron®

Processors

CPU Socket LGA 1700

Chipset Intel®

B760 Chipset

Expansion Slots 1x PCIe 4.0 x16 slot

2x PCIe 4.0 x1 slots

Display Interface Support 4K@30Hz as specified in HDMI™ 1.4, DisplayPort

1.4, VGA – Requires Processor Graphics

Memory Support 4 DIMMs, Dual Channel DDR4-4800+MHz(OC)

Storage 2x M.2 Gen4 x4 64Gbps slots,

4x SATA 6Gbps ports

USB ports 1x USB 3.2 Gen 2 10Gbps (1 Type-C),

3x USB 3.2 Gen 1 5Gbps (3 Type-A),

8x USB 2.0

LAN Realtek®

RTL8111H Gigabit LAN

Audio 8-Channel (7.1) HD Audio with Audio Boost
